Sonata Elite User Manual, introduces the product's quiet computing features, specifications, illustrations, hardware installation guides, front panel wiring steps, cooling systems, etc.
The Sonata Elite is a high‑performance CPU cooler from Antec, featuring a 120 mm TriCool™ fan and multiple I/O connectors for modern motherboards. It supports Mini‑ITX, micro‑ATX and standard ATX platforms and is designed for quiet operation while delivering strong cooling.
Key specifications include a 120 × 25 mm fan with three speed settings, dual USB 2.0 ports, an eSATA port, and HD Audio/AC’97 output. The cooler measures 48.1 cm × 20.5 cm × 44 cm and weighs 9.8 kg, making it suitable for a range of desktop builds. This manual is written in Chinese.
| Fan size | 120 × 25 mm |
|---|---|
| Fan voltage | DC 12 V (10.2 V – 13.8 V) |
| Fan current (max) | 0.24 A |
| Dimensions | 48.1 cm × 20.5 cm × 44 cm |
| Weight | 9.8 kg |
| USB ports | 2 × USB 2.0 |
| eSATA port | 1 × eSATA |
The fan runs on DC 12 V, with an acceptable range of 10.2 V to 13.8 V.
The Sonata Elite includes two USB 2.0 ports.
