Mitsubishi Electric C6/C64/C64T CNC Parameter Manual

This manual provides a guide to the parameters used with the CNC MELDAS C6/C64/C64T.

Brand: Mitsubishi Electric
Document type: User Manual
Language: English
Pages: 317
File format: PDF
File size: 3 MB
Published: 18 October, 2023
Updated: 18 October, 2023
MD5 checksum: 172272B82CA6EA8F874D8BB6F5F64F4B
PDF: Mitsubishi Electric C6/C64/C64T CNC Parameter Manual PDF

About this manual

This manual serves as a comprehensive guide to the parameters used with the MELDAS C6/C64/C64T CNC system. It explains each parameter, its function, and the valid setting ranges, helping users configure the controller for specific machine tools.

The document also emphasizes safety, ranking precautions as DANGER, WARNING, or CAUTION, and advises consulting the machine maker's Specification Manual for any restrictions. References to related manuals (Instruction Manual, Programming Manual, Servo Parameter Manual) are included for deeper detail.

What's inside

Parameter Screens
Machining Parameters
Base Specifications Parameters
Axis Specifications Parameters
Servo Parameters
Spindle Parameters
Machine Error Compensation
PLC Constants
Macro List
Safety Precautions

Specifications

Input unit options	B = 1 µm, C = 0.1 µm
Axis type selection (parameter #1017)	0 = Linear axis, 1 = Rotary axis
Motor rotation direction (parameter #1018)	0 = Clockwise, 1 = Counter‑clockwise
Diameter specification mode (parameter #1019)	0 = Movement amount, 1 = Diameter dimension

Frequently asked questions

What does parameter #1017 control?

Parameter #1017 selects whether an axis is linear (0) or rotary (1).
