The Zebra TTP 7030 is a fast, reliable thermal receipt printer designed for unattended operation in harsh environments such as extreme heat, cold, and vibration. It includes a jam‑preventing loop presenter, guillotine cutter, and pull detector for trouble‑free performance, with maintenance limited to media roll replacement.
The manual lists technical specifications, including print width options of 80 mm (3.5 in) to 112 mm (4.4 in), a resolution of 203 dpi, and USB plug‑and‑play connectivity compatible with Windows. Electrical requirements, physical dimensions, supported bar‑code symbologies, and optional interfaces such as RS‑232 are also detailed. This manual is written in Chinese.
| Resolution | 203 dpi (8 dots/mm) |
|---|---|
| Print width (80) | 2.83" (72 mm) |
| Print width (112) | 4.09" (104 mm) |
| Print length | 2.95" (75 mm) to 24" (600 mm) |
| Print speed | 2.95" (75 mm)/sec |
| Media thickness | .002" (.054 mm) to .005" (.13 mm) |
| Electrical (80) | 24 VDC, ±10%, average 2.5 A, peak 8.5 A |
| Electrical (112) | 24 VDC, ±10%, average 3.5 A, peak 11 A |
| Weight | 5.51 lbs (2.5 kg) |
It supports media widths from 80 mm (3.5 in) up to 112 mm (4.4 in).
The printer connects via a USB interface and works as a plug‑and‑play device with Windows, or can be addressed directly from kiosk software in text mode.
It requires 24 VDC with ±10% tolerance, drawing an average of 2.5 A (peak 8.5 A) for the 80 mm model and 3.5 A (peak 11 A) for the 112 mm model.
Supported symbologies include Linear Code 39, Code 128, EAN‑8, EAN‑13 with extensions, and Interleaved 2‑of‑5.
