SMS1210 digital segment LCD display module (LCM), using digital segment LCD display (LCD), can display 12-digit numbers, 9 segment prompts and 11 decimal points, low power consumption, and is widely used in telephone billing devices, smart display instruments.
The SMS1210 is a digital LCD display module that can show two numeric digits and one decimal point. It is low‑power and designed for use with micro‑controllers via a three‑wire serial interface.
The manual lists the main technical parameters, serial interface signals, physical dimensions, and the address mapping table needed to control the display. This manual is written in Chinese.
| Display capacity | 2 digits + 1 decimal point |
|---|---|
| Operating current | 1.5 mA |
| Character height | 12.0 mm |
| Interface type | Three‑wire serial interface |
The module can display two numeric digits and one decimal point.
It uses a three‑wire serial interface.
The module draws about 1.5 mA during operation.
