VFD-F series AC motor drive user manual, introduces the installation, parameter setting, fault troubleshooting and other products
This manual covers all aspects of the Delta VFD-F series AC motor drive, including safety warnings, delivery inspection, storage, installation, wiring, digital operator panel functions, parameter tables, error messages, fault diagnosis, standard specifications and optional accessories. It is intended for professional electrical engineers and service technicians who will install, commission and maintain the drive.
Key sections guide the user through proper grounding, power‑off procedures, correct mounting orientation, environmental requirements, and detailed wiring diagrams. The document also lists technical specifications such as power ratings, input/output voltage ranges, frequency range, and relay card limits, helping users select appropriate components and perform safe operation. This manual is written in Chinese.
| Power Rating | 7.5 HP / 5.5 kW |
|---|---|
| Input Voltage | 3‑phase 380‑480 V, 50/60 Hz, 14 A |
| Output Voltage | 0‑480 V, 3‑phase, 13 A, 9.9 kVA |
| Frequency Range | 1.5 ~ 120 Hz |
