VFD-F series AC motor drive user manual, introduces the installation, parameter setting, fault diagnosis, troubleshooting and daily maintenance of the drive
The manual covers all aspects of using the Delta VFD-F series AC motor drives, including delivery inspection, storage, installation, wiring, and operation of the digital controller. It also details functional parameters, error messages, and maintenance procedures.
Safety information is emphasized throughout, with clear warnings about grounding, high‑voltage hazards, and the requirement that only qualified personnel perform installation and servicing. Technical data such as input/output specifications, frequency range, and recommended accessories are provided in dedicated sections. This manual is written in Chinese.
| Input voltage | 380-480V 50/60Hz 14A |
|---|---|
| Output voltage / current | 0-480V 13A 9.9kVA 7.5HP |
| Frequency range | 1.5~120Hz |
| Enclosure type | TYPE 1 |
| Maximum current rating | 5000A RMS |
The drive must be properly grounded, the power must be turned off before wiring, and only qualified electrical engineers should perform installation and adjustments.
Store it in a clean, dry place with ambient temperature between –20 °C and +60 °C and relative humidity between 0 % and 90 % without condensation.
