This document is the assembly instructions for Top Flite's 1/7th scale dummy radial engine. It includes a list of tools and materials needed, assembly steps, and warnings.
This manual provides assembly and finishing instructions for the Top Flite RADIAL01 Dummy Radial Engine. The product is a 1/7th scale replica of Pratt & Whitney radial engines, patterned to fit models like the F4U Corsair and AT-6 Texan. It serves as an air-flow baffle to improve engine cooling in flying models or enhances scale appearance for static displays.
This Radial fits any cowls with a frontal opening of 6-1/2" to 7".
The Radial must be modified to permit cooling airflow to the engine.
You need to cut 18 pieces that are 1-1/4" long to use for the Push Rod Tubes.
