This is an assembly manual for an airplane cockpit.
This manual provides step-by-step assembly instructions for the Top Flite Gold Edition Piper Arrow II, a scale radio-controlled model airplane. The kit includes options for building with or without corrugated control surfaces and fixed or retractable landing gear.
The guide covers the construction of all major components, including tail surfaces, wings, fuselage, and engine installation. It also details final assembly steps such as painting, decal application, and systems hookup.
| Wingspan | 81 in [2060mm] |
|---|---|
| Weight | 12-14 Ib [5440-6350 g] |
| Fuselage Length | 61.5 in [1560mm] |
| Radio Requirement | 6-channel, 1 high-torque servo |
| Engine Size (Two-stroke) | .61—.91 cu in [10.0-15.0cc] |
| Scale | 1:4.6 |
The manual recommends a .61—.91 cu in two-stroke or four-stroke engine.
Yes, the manual provides instructions for building the model with either fixed or retractable landing gear.
Yes, you can replace the die-cut, corrugated skins with regular sheeting if you do not wish to include them.
