This document provides information about the features and characteristics of the UIM-1 and UIM-2 Universal Input Modules, as well as important safety instructions.
The SCADA 3000 Universal Input Module is an optional component designed to interface with various sensors and transducers. It features eight channels capable of handling Normally Open/Normally Closed dry contacts, digital logic, run time accumulation, 0-5V analog signals, 4-20mA current loops, and 10K thermistors for temperature measurement in both Celsius and Fahrenheit.
| Channels | eight channels |
|---|---|
| Resolution | 12-bit resolution |
| Power Supply Range | 10-15VDC |
| Power Consumption | 1.5 Watts |
It interfaces with Normally Open/Normally Closed dry contacts, digital logic, Run time Accumulation, 0-5V analog, 4-20mA analog and 10K thermistor °C & °F.
The module can operate in a temperature range of 32°F to 158°F (0°C to 70°C).
The module operates on a 10-15VDC power source.
