Lab.gruppen fP 6400 Power Amplifier User Manual

This file is the product manual of QSC PLX1212-II digital amplifier, which mainly introduces the features and usage of this product

Brand: Lab.gruppen
Category: Other Electronics
Document type: User Manual
Language: English
Pages: 20
File format: PDF
File size: 1.1 MB
Published: 06 August, 2012
Updated: 30 September, 2023
Model: fP 6400
MD5 checksum: 5217E67D0F2B1E21AF1EEDCDECD69C6E
PDF: Lab.gruppen fP 6400 Power Amplifier User Manual PDF

About this manual

The document is a user manual for the Lab.gruppen fP 6400, a professional audio power amplifier. It covers unpacking, front and rear panel features, various operation modes including stereo, tandem, bridge mono, and impedance matching using MLS technology. The guide details input connections, speaker wiring, and specific operational precautions regarding gain adjustment and signal levels.

What's inside

Approvals
Warnings
Introduction
Front Panel Features
Rear Panel Features
Installation
Connections
Operation
Protection Features
Specifications

Specifications

Operating Temperature Limit	90°C
VHF Protection Threshold	12 kHz
Input Voltage Rating	200-240V, 50-60Hz
Safety Standard (US)	ANSI/UL 6500

Frequently asked questions

Can I connect an amplifier output to a battery?

No, you must not connect the amplifier output to any other voltage source, such as a battery or mains source.

What is the maximum operating temperature of the amplifier?

The over temperature protect indicator illuminates if the amplifier is going to operate above its maximum operating temperature of 90°C.

At what frequency does the VHF protect indicator illuminate?

This indicator illuminates if signals above 12 kHz are continuously present at full power at the output terminals.
