IXYS IXGR 32N60CD1 HiPerFAST IGBT Datasheet

This document is a technical datasheet of the HiPerFASTTM IGBT with Diode ISOPLUS247TM from IXYS. The product has high current handling capability and can be used in UPS, switch-mode and resonant-mode power supplies, AC motor speed control, DC servo and robot drives, DC choppers and other applications.

Brand: IXYS
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 5
File format: PDF
File size: 125 KB
Published: 11 July, 2012
Updated: 30 September, 2023
MD5 checksum: 90D06D9EA4D0E57C0C32F96EF8C73C3E
PDF: IXYS IXGR 32N60CD1 HiPerFAST IGBT Datasheet PDF

About this manual

This document is a datasheet for the IXYS IXGR 32N60CD1, a HiPerFAST™ IGBT with Diode featuring an ISOPLUS247™ electrically isolated backside. It is designed for high-current handling and fast switching speeds, suitable for applications such as uninterruptible power supplies, switched-mode power supplies, and motor drives.

What's inside

Maximum Ratings
Electrical Characteristics
Reverse Diode Characteristics
Package Outline
Applications
Features
Graphs and Curves

Specifications

Package Type	TO-247AD

Frequently asked questions

What are the applications for the IXGR 32N60CD1?

It is used in uninterruptible power supplies, switched-mode power supplies, AC motor speed control, and DC servo drives.

What is the maximum lead temperature for soldering?

The maximum lead and tab temperature for soldering is 300 °C for 10 seconds at 1.6 mm from the case.
