This document introduces the technical data and features of the FMP series filters. The FMP filters are available in different models and working pressures to suit different flow rate requirements. The filters are made of different materials, providing pressure and heat resistance. Additionally, the filters are equipped with check valves and bypass valves, as well as different types of filter elements. The filter elements can be selected based on different working environments and requirements. The filters also have excellent sealing performance and can be equipped with seals made of different materials. The entire series of filters offers reliable performance and stable working pressure.
This document provides technical specifications for the MP Filtri FMP series of hydraulic filters. It details construction materials such as cast iron bodies and brass bypass valves, along with operating limits including a maximum pressure of 280 bar and a temperature range from -25°C to +110°C.
| Maximum operating pressure | 280 bar (28 MPa) |
|---|---|
| Test pressure | 420 bar (42 MPa) |
| Burst pressure | 840 bar (84 MPa) |
| Operating temperature range | -25°C to +110°C |
| Bypass valve opening pressure | 6 bar (+10%) |
The maximum operating pressure is 280 bar (28 MPa).
The filter operates from -25°C to +110°C.
