The NCP1086 is a 1.5A adjustable and 3.3V fixed output linear regulator that can be used as a post regulator and microprocessor supply. It has fast loop response and low dropout voltage, making it ideal for applications where low voltage operation and good transient response are important.
The NCP1086 is a 1.5 A adjustable and 3.3 V fixed output linear regulator designed for use as a post regulator and microprocessor supply. It features a fast loop response and low dropout voltage, making it ideal for applications requiring low voltage operation and good transient response. The device is available in TO-220-3, D2PAK-3, and SOT-223 packages.
| Output Current | 1.5 A |
|---|---|
| Output Accuracy | +1% Over Temperature |
| Dropout Voltage (Typical) | 1.05 V @ 1.5A |
| Supply Voltage | 7.0 V |
| Operating Temperature Range | -40 to +70 °C |
| Junction Temperature | 150 °C |
The adjustable output voltage device sets the output voltage within a 1.25 V to 5.5 V range.
The device is available in TO-220-3, surface mount D2PAK-3, and SOT-223 packages.
Yes, device protection includes overcurrent and thermal shutdown.
