This manual provides you with the necessary information for the correct use of the instrument.
The HI 96751C is an auto-diagnostic portable microprocessor meter designed for measuring sulfate content in water samples within a range of 0 to 150 mg/L. It features an advanced optical system based on a Light Emitting Diode (LED) and a narrow band interference filter to ensure accurate and repeatable readings. The instrument includes a CAL CHECK validation function to verify performance using NIST traceable standards.
| Range | 0 to 150 mg/L |
|---|---|
| Resolution | 1 mg/L |
| Accuracy | +1 mg/L 5% of reading @ 25°C |
| Light Source | Light Emitting Diode |
| Light Detector | Silicon Photocell with narrow band interference filter @ 466 nm |
| Environment | 0 to 50°C (32 to 122°F); max 95% RH non-condensing |
| Battery Type | 1x9 volt |
| Dimensions | 192 x 104 x 69 mm (7.6 x 4.1 x 2.7") |
| Weight | 360 g (12.7 oz) |
The meter measures sulfate content in water samples in the 0 to 150 mg/L (ppm) range.
Sulfate is precipitated with barium chloride crystals, and the light absorbance of the suspension is measured.
A 'Battery low' message appears indicating the battery must be replaced soon, and a 'Dead battery' message locks the meter if the battery is depleted.
