This document provides technical data for the Di-Soric OGU 010 G3K-TSSL, an infrared proximity switch. The device operates using a wavelength of 870 nm and features a switching distance of up to 25 mm.
Key specifications include a supply voltage range of 10...30 V DC, a maximum output current of 100 mA, and an operating temperature range from -10°C to +65°C. The sensor utilizes an NPN open collector output with a short-circuit-proof design. This manual is written in German.
| Supply voltage | 10...30 V DC |
|---|---|
| Output current | 100 mA |
| Operating temperature | -10...+65°C |
The device emits infrared light with a wavelength of 870 nm.
It is capable of handling up to 200 mW of optical power.
