This is the instruction manual of HI 93700 Ammonia Low Range ISM
The HI 93700 is a colorimeter designed to measure ammonia nitrogen (NH3-N) content in water, wastewater, and seawater within a range of 0.00 to 3.00 mg/L. The instrument utilizes an exclusive positive-locking system for cuvet placement and features an auto-shut-off function that activates after 10 minutes of non-use. It operates using a light-emitting diode light source at 470 nm and a silicon photocell detector, adhering to the ASTM D1426-92 Nessler method.
| Range | 0.00 to 3.00 mg/L |
|---|---|
| Resolution | 0.01 mg/L |
| Accuracy | +/-0.04 mg/L +/-4% of reading |
| Light Source | Light Emitting Diode @ 470 nm |
| Light Detector | Silicon Photocell |
| Environment | 0 to 50°C (32 to 122°F) |
| Auto-Shut off | After 10' of non-use |
| Dimensions | 180 x 83 x 46 mm |
| Weight | 290 g |
The meter measures ammonia nitrogen content in the 0.00 to 3.00 mg/L (ppm) range.
The instrument measures ammonia nitrogen content in water, wastewater, and seawater within a range of 0.00 to 3.00 mg/L with a resolution of 0.01 mg/L.
The meter will turn itself off after 10 minutes of non-use.
You must add 4 drops of the First Reagent to perform the test.
