The DS4812 is a dual operational amplifier from Texas Instruments that combines high slew rate and rail-to-rail output swing. The device provides 10V/µs of slew rate and 6.5 MHz of bandwidth while only consuming 1.5 mA of supply current per channel. Ideal low voltage BiFET substitute for low gain, high speed applications.
The DS4812 is a BiCMOS dual operational amplifier designed for high-speed, low-voltage applications. It combines a high slew rate of 10V/µs with a bandwidth of 6.5 MHz while maintaining a low supply current consumption of 1.5 mA per channel. The device offers rail-to-rail output swing and is suitable as a substitute for BiFET amplifiers in low-gain, high-speed circuits.
| Slew Rate (Typical) | 10 V/µs |
|---|---|
| Supply Voltage Range | 2.5 to 5.5V |
| Output Swing Type | Rail-to-Rail |
| Operating Temperature | 0°C to +70°C |
The device operates with a supply voltage ranging from 2.5V to 5.5V.
The DS4812 provides a high slew rate of 10V/µs.
Yes, the DS4812 features a rail-to-rail output swing.
