R3132x/R3133x Series are CMOS-based low voltage detector ICs with built-in delay circuit, high detector threshold accuracy, and ultra low supply current, which can operate at low voltage.
The Ricoh R3132x/R3133x Series are CMOS-based low voltage detector integrated circuits featuring a built-in delay circuit, high detector threshold accuracy, and ultra-low supply current. These devices operate within a wide voltage range of 0.8V to 6.0V and can function as system reset generators.
| Supply Current (Typ) | 0.8nA |
|---|---|
| Operating Voltage Range | 0.8V to 6.0V |
| Detector Threshold Accuracy | Typ. ±100ppm/°C |
| Output Types | Nch Open Drain and CMOS |
| Packages | SC-82AB, SON1612-6 |
| Power-on Reset Delay Time | Typ. 240ms |
The devices operate within a supply voltage range of 0.8V to 6.0V at 25°C.
The series offers two output types: Nch Open Drain type and CMOS type.
