This is a high-resolution wireless camera that can be used for outdoor security and other scenarios.
The EverFocus EZ180 is a high-resolution 1/3" image format B/W CCD camera designed for outdoor surveillance applications such as parking lots, gas stations, and shopping malls. It features a sturdy aluminum shell, a built-in heater for operation in temperatures down to -46°C, and offers two types of built-in vari-focal lenses for versatile applications. The camera provides a high resolution of 560 TV lines and includes features like auto gain control, flickerless operation, and line lock synchronization.
| Pickup Device | 1/3" SONY B/W CCD |
|---|---|
| Picture Elements | 768 x 494 (EIA) |
| Horizontal Resolution | 560 TV lines |
| Video Output | BNC 1.0Vp-p, 75 ohm |
| Lens Focal Length | Vari-focal lens f=3.5~8mm |
| Sensitivity | 0.1 lux/F=1.6 |
| Weatherproof Rating | IP66 |
| Power Source | 12VDC/24VAC |
| Operating Temperature | -46°C ~ 50°C |
The camera can operate in temperatures between -46°C and 50°C.
The heater turns on automatically when the temperature drops to 10°C.
The default setting for AGC is On.
No, Line-Lock sync mode operation is only possible when used with an AC power source.
