bfq166 is a n-type video transistor produced by philips. it features low output capacitance, high gain bandwidth, good thermal stability, excellent reliability, high current applicability and surface mounting.
The Philips BFQ166 is an NPN video transistor designed for use in video amplifier cascode drivers for high-resolution color graphics monitors. It features low output capacitance, high gain bandwidth, and good thermal stability. The device utilizes gold metallization to ensure excellent reliability and is available in a surface-mount SOT223 plastic package.
| Collector-base voltage | 20 V |
|---|---|
| Collector-emitter voltage | 19 V |
| Collector current | 500 mA |
| Total power dissipation | 2 W |
| DC current gain | 50 to 60 |
| Transition frequency | 1 GHz |
| Package type | SOT223 |
The maximum total power dissipation is 2 W when the soldering point temperature is below 105 °C.
The maximum DC collector current is 500 mA.
This surface mounted package has 4 leads: emitter, base, emitter, and collector.
