SIRIUS SIR-PNR1 Installation Guide

SIR-PNR1 user manual, for Pioneer brand compatible SIRIUS satellite radio

Brand: SIRIUS
Category: Car Accessories
Document type: Installation Guide
Language: English
Pages: 14
File format: PDF
File size: 710 KB
Published: 06 July, 2012
Updated: 30 September, 2023
MD5 checksum: B8C4FE1DB026EC71092074E98312A2CD
PDF: SIRIUS SIR-PNR1 Installation Guide PDF

About this manual

This guide provides step-by-step instructions for installing the SIR-PNR1 satellite radio tuner, which is designed to work with Pioneer headunits designated as 'SAT RADIO READY'. The document covers the installation of the magnetic micro antenna on the vehicle roof and the routing of the cable to the interior.

What's inside

Package Contents
Warnings and Cautions
Mounting the Tuner
Installing the Antenna
Optimum Antenna Mounting Locations
Wiring and Cable Connections
System Connection Examples
Activating Your SIRIUS Subscription
Specifications

Specifications

Power Requirements	11-16 Volts DC
Fuse Type	1-AMP (Glass)
Chassis Size	126.75mm x 125.75mm x 34.75mm
Antenna Type	Mini-Magnetic
Antenna Cable Length	21' (single micro-cable)
Connector Type	SMB (Right-angle)
Audio Output	1V (Fixed)
Included Cable	2.5 Meter IP-Bus
