This is a satellite radio user manual, which introduces the installation, use methods, etc. of the radio
The SIRIUS Sportster SP5 is a satellite radio receiver designed for use with the SUPH1 Home Kit, SUPV1 Vehicle Kit, or SUBX1 Boombox. This manual provides instructions for installing the radio in a vehicle or home environment, connecting it to various audio systems, and subscribing to the SIRIUS service. It details the features of the front panel and remote control, including navigation, search modes, and menu settings.
| Satellite Frequencies | 2322.293/2330.207 MHz |
|---|---|
| Terrestrial Frequencies | 2326.250MHz |
| Power Requirements | 5.2 Volts, Negative Ground, DC |
| Audio Output | 2.8V (normal); 3.0V (max.) (Peak-to-Peak) |
| Total Harmonic Distortion | <0.3% |
| Signal-to-noise | Greater than 75dB |
| Operation Temperature | -20° to +85° C (-4° to +185° F) |
| Radio Dimensions | 114.2mm x 62.5mm x 16.9mm (4.5” x 2.5” x 0.6”) |
| Radio Weight | 105g (3.7 oz. ) |
| Remote Control Battery | CR2025 |
| Cigarette Lighter Adapter Fuse | 2A Slow Blow |
| Cigarette Lighter Adapter Cable Length | 1.8m (6ft.) |
| Antenna Type | Low Profile Magnetic Antenna |
| Antenna Cable Length | 21’ (single micro-cable) |
| Antenna Connector Type | SMB (right-angle) |
| Audio Out Interface | 1/8” / 3.5mm Stereo Jack |
It is compatible with the SUPH1 Home Kit, SUPV1 Vehicle Kit, or the SUBX1 Boombox.
No, it must be powered from the cigarette lighter or a similar power port using the included adapter.
The radio is designed to operate between -20° to +85° C (-4° to +185° F).
The remote control requires a CR2025 battery.
