This manual introduces the features and capabilities of the SIRIUS Starmate ST5 Dock & Play Radio, including SIRIUS Replay™, Memo function, easy-to-read wide-angle 5-line display, built-in wireless FM transmitter and full-function wireless remote control.
The SIRIUS Starmate ST5 is a portable satellite radio designed to play in your car or with available Universal Docking accessories. Key features include SIRIUS Replay™ for pausing and rewinding live radio, a Memo function to store favorite songs and artists, an easy-to-read 5-line display, and a built-in wireless FM transmitter.
| Satellite Frequencies | 2322.293/2330.207 MHz |
|---|---|
| Power Requirements | 5.2 Volts, Negative Ground, DC |
| Audio Output (normal) | 2.8V |
| Total Harmonic Distortion | <0.2% |
| Signal-to-noise ratio | Greater than 73dB |
| Operation Temperature | -20° to +85° C (-4° to +185° F) |
| Radio Dimensions | 124.2mm x 48.5mm x 16mm (4.9" x 1.9" x .0.6") |
| Remote Control Battery | CR2025 |
The radio is designed to operate between -20° and +85° C (-4° to +185° F).
The Vehicle Dock must be powered from the vehicle's cigarette lighter or similar power port using the included adapter; it cannot be connected directly to the 12VDC system.
The remote control requires a CR2025 battery.
