This is the SIRIUS InV SV2 user manual, which introduces the features and characteristics of SIRIUS InV SV2, as well as how to install, use and subscribe to SIRIUS service.
The SIRIUS InV SV2 is a Plug-n-Play satellite radio designed to provide digital entertainment in any vehicle. This manual guides users through unboxing, installing the adhesive dash mount or cigarette lighter adapter, and connecting the low-profile magnetic antenna.
Once installed, the guide details how to operate the display screen, change channels and categories, access menu options like SIRIUS ID and FM Transmitter settings, and manage audio levels. It also includes specific troubleshooting steps for common issues.
| Satellite Frequencies | 2322.293/2330.207 MHz |
|---|---|
| Terrestrial Frequencies | 2326.250MHz |
| Radio Power Requirements | 4.9–5.6 Volts, Negative Ground, DC |
| Cigarette Lighter Adapter Power Requirements | 9–16 Volts, Negative Ground, DC |
| Audio Output | 550mVrms (+/- 50mVrms) |
| Total Harmonic Distortion (THD) | <0.2% |
| Signal-to-noise (S/N) | Greater than 73dB |
| Fuse Requirement | 2A ATC |
| Radio Dimensions | 122.0mm x 48.0mm x 18.2mm (4.8” x 1.9” x 0.7”) |
| Antenna Type | Low Profile Magnetic Antenna |
The radio is designed to operate between -20° and +85° C (-4° to +185° F).
The package includes the SIRIUS InV SV2 Radio, adhesive dash mount, cigarette lighter adapter, antenna cover/tail, alcohol swab, magnetic antenna, and user guide.
Turn the power off immediately and disconnect the unit from any power source.
