This manual introduces the features and capabilities of SIRIUS Starmate ST4 Dock & Play Radio.
The SIRIUS Starmate ST4 is a portable satellite radio designed to work with various docking kits, including the Universal Home Kit (SUPH1), Universal Vehicle Kit (SUPV1), and the Boombox (SUBX1). This manual covers setup procedures for different installation scenarios, such as vehicle docks, magnetic antennas, and wireless connections using FM extenders. It also details how to connect the radio to a vehicle's audio system via direct wired or FM transmission methods.
| Satellite Frequencies | 2322.293/2330.207 MHz |
|---|---|
| Power Requirements | 5.2 Volts, Negative Ground, DC |
| Audio Output (Normal) | 2.8V |
| Total Harmonic Distortion | <0.2% |
| Signal-to-noise Ratio | Greater than 73dB |
| Operation Temperature | -20° to +85° C (-4° to +185° F) |
| Radio Dimensions | 124.2mm x 48.5mm x 16mm (4.9” x 1.9” x .0.6”) |
| Remote Control Battery | CR2025 |
The radio operates between -20° to +85° C (-4° to +185° F).
It must be powered from a vehicle's cigarette lighter or similar port using an adapter; it cannot connect directly to 12VDC.
The remote control requires a CR2025 battery.
