LMH6718 is a dual, low cost high speed (130MHz) buffer which features user programmable gains of +2, +1, and -1V/V
The LMH6718 is a dual, low cost high speed buffer featuring user programmable gains of +2, +1, and -1V/V. It utilizes an advanced complementary bipolar process to maintain consistent performance over a wide range of signal levels with a linear phase response up to one half of the -3dB frequency.
Key features include 0.1dB gain flatness to 30MHz, differential gain and phase errors of .04% and .03°, and superior dynamic performance with a 130MHz small-signal bandwidth and 600V/us slew rate. The device is optimized for professional and consumer video applications as well as battery-powered systems requiring high output drive current.
| Bandwidth (Ay = +2) | 130 MHz |
|---|---|
| Output Current | 200 mA |
| Slew Rate | 600 V/us |
| Supply Voltage Range | +2.5V to +6V |
The device features user programmable gains of +2, +1, and -1V/V.
The LMH6718 delivers high output drive current of 200mA.
