Introduction of AirLine Micro Camera system
The Samson AirLine Micro is a breakthrough wireless microphone technology featuring an integrated omni-directional microphone in the AH2 single earset transmitter. The system includes the AR2 micro receiver, which features a rugged aluminum chassis with retractable antennas, and the AR2D dock for stability.
This guide covers the complete setup process, including charging the internal lithium-ion batteries, connecting audio equipment, and adjusting volume levels via the Multi-Function Switch. It also details how to use the tone-key auto-mute feature and interpret status indicator lights on both the transmitter and receiver.
| Battery Type | Lithium ion |
|---|---|
| Battery Operation Time | 10 hours |
| Audio Output | 1/8" unbalanced |
| Input Sensitivity | Microphone or line level |
| AC Adaptor Range | 100V - 240V |
Plug the AC adaptor into a power socket, connect the USB Y-Cable to it, and plug the mini-USB connectors into the AH2 transmitter and AR2 receiver.
Press and hold the Multi-Function Switch until the Status Indicator turns off, then press it again for 5 seconds to enter Volume Adjustment mode.
Press the Multi-Function Switch once to toggle the mute function.
