SAMSON STAGE 5H user manual

This is a manual of Samson Stage 5 Series Wireless System. It introduces the system components, usage and features.

Brand: Samson
Category: Other Electronics
Document type: User Manual
Language: English
Pages: 12
File format: PDF
File size: 673 KB
Published: 05 July, 2012
Updated: 30 September, 2023
MD5 checksum: D2CDA22A8C40B096595757DE7FDDCF04
PDF: SAMSON STAGE 5H user manual PDF

About this manual

This document is the Owner's Manual for the Samson Stage 5 Series Professional VHF Wireless Microphone System. It includes guided tours of the SR5 receiver and HT5 transmitter front and rear panels, along with step-by-step instructions for setting up and using the system.

What's inside

Introduction
Guided Tour - SR5 Front Panel
Guided Tour - SR5 Rear Panel
Guided Tour - HT5
Setting Up and Using Your Stage 5 Series System
Specifications

Specifications

Frequency Range	174.6 - 213.2 MHz
Receiver Type	SRS receiver
Microphone Element	Samson HS dynamic
DC Input Voltage	12 volt
Power Adapter Current	500 mA
Balanced Output Impedance	600 Ohm
Unbalanced Output Impedance	5K Ohm
Battery Type	9-volt alkaline

Frequently asked questions

What is the frequency range of the Stage 5 Series system?

The system operates in the 174.6 - 213.2 MHz frequency range.

What type of battery is recommended for the HT5 transmitter?

A standard 9-volt alkaline battery is recommended, specifically the Duracell MN 1604 type.

Can the unbalanced and balanced outputs be used simultaneously?

Yes, if required, both the unbalanced and balanced outputs can be used simultaneously.
