PHILIPS TEA1506P; TEA1506AP; TEA1506T; TEA1506AT handbook

TEA1506P; TEA1506AP; TEA1506T; TEA1506AT is a GreenChipII SMPS control IC with features including universal mains supply operation, high level of integration, green features, and protection features. The product can be widely used in TV, monitor supplies, adapters, chargers, and other applications that demand an efficient and cost-effective solution up to 150W.

Brand: Philips
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 22
File format: PDF
File size: 120 KB
Published: 04 July, 2012
Updated: 29 September, 2023
MD5 checksum: 6E67C154F1FDF8C04EF24A7F035A27BC
PDF: PHILIPS TEA1506P; TEA1506AP; TEA1506T; TEA1506AT handbook PDF

About this manual

This document is a product specification datasheet for the Philips GreenChip™II SMPS control IC, specifically models TEA1506P, TEA1506AP, TEA1506T, and TEA1506AT. These integrated circuits are designed to provide a high level of integration for cost-effective switched mode power supplies with low external component counts.

What's inside

Features
Applications
Ordering Information
Package Types
Pinning
Functional Description
Multi modes operation
Protection features

Frequently asked questions

What is the maximum power level for which this IC is designed?

The device can be used in applications that demand a solution up to 150 W.

What happens if the output voltage exceeds the overvoltage protection trip level?

The IC assumes a true OVP after detecting typical 10 cycles of subsequent events and switches the power MOSFET off.

At what voltage level does switching restart for the TEA1506 model?

Switching recommences only when the Vcc voltage drops below a level of about 4.5 V.
