LM20EP Enhanced Plastic 2.4V, 10µA, SC70, micro SMD Temperature Sensor is a precision analog output CMOS integrated circuit temperature sensor produced by National Instruments Corporation. The working temperature range is -55˚C to +130˚C, and the power supply operating range is +2.4 V to +5.5 V. The output signal of the sensor is linearly related to the temperature, and the linearity of the output signal is ±1.5˚C. The power consumption is less than 10µA, and the self-heating in the static state is less than 0.02˚C.
The LM20EP is a precision analog output CMOS integrated-circuit temperature sensor that operates over a -55°C to +130°C temperature range. The power supply operating range is +2.4 V to +5.5 V, and the transfer function is predominantly linear with slight predictable parabolic curvature.
| Temperature Range | -55°C to +130°C |
|---|---|
| Power Supply Voltage Range | +2.4 V to +5.5 V |
| Accuracy at +30°C | +1.5°C (max) |
| Quiescent Current | < 10 pA |
The accuracy is +1.5°C to +4°C maximum when specified to a parabolic transfer function.
The device is available in an SC70 and a micro SMD package.
The maximum junction temperature (Tjmax) is +150°C.
