HTS PAL is a sample autosampler produced by Varian. It is characterized by precision and high throughput, and is suitable for high-throughput screening, quality control applications or LC/MS flow injection analysis.
The Agilent HTS PAL is an automated liquid handling system designed for precise and accurate sample injections in LC and LC/MS applications. It features a unique XYZ robot mechanism with syringe-only technology to facilitate fast sampling and rapid vial-to-vial transfers, making it ideal for high-throughput screening (HTS) and QA/QC workflows.
The instrument offers task-oriented programming via the Varian MS Workstation software and includes a Fast Wash Station to eliminate sample carryover. Key specifications include positioning precision of +0.1 mm, an injection volume range of 0.1 µL to 5000 pL, and a capacity for up to 648 standard vials or various plate configurations.
| Positioning precision | +0.1 mm |
|---|---|
| Injection Volume Range | 0.1 ul - 5000 pL |
| Injection Speed | 0.01 Lfsec - 250 L/sec. |
| LC Injector | 1 electrically actuated fast switching 6-port valve |
| Sample Capacity (Standard Vials) | 648 2 mL standard vials |
| Dimensions (Height x Width x Depth) | 25.5 in./64.8 em x 32.6 in./82.8 cm x 15.2 in.f38.5 em |
| Weight | 10 kg |
The HTS PAL is controlled by Varian MS Workstation software.
Yes, GLP comes standard with the MS Workstation software and includes optional tools to facilitate 21 CFR Part 11 compliance.
The station contains two user-selectable cleaning solvents.
