This document describes the features and characteristics of the M-AUDIO StudioPro4 speakers, including woofer, tweeter, sub-frequency port, mid-boost control, enclosure, and network & power amplifiers.
The M-Audio StudioPro 4 is a self-powered desktop monitor designed to deliver pure, original sound without coloration. It utilizes a custom-tuned cabinet with an optimized 4-inch woofer and a 1-inch Mylar dome tweeter featuring OptImage wave guide technology for improved stereo imaging.
The manual provides instructions on unboxing the contents, connecting the speakers via speaker wire or RCA cables, and using the front panel volume control and headphone output. It also details the rear panel features, including the Mid-Boost control for room EQ compensation and the sub-frequency port.
| Woofer Diameter | 4 inches |
|---|---|
| Tweeter Type | 1-inch Mylar dome |
| Frequency Response (LF) | 20Hz-20kHz |
| RMS SPL | 101.5dB |
| Power Output | 18W/4Q |
| Dimensions (HxWxD) | 21.6 cm x 14.6 cm x 15.9 cm |
The box contains two speakers, one speaker wire, a mini jack to RCA audio cable, an AC power cord, test results, and this manual.
The hole in the rear panel called a Sub-Frequency Port is designed to discharge extreme low frequencies.
It allows compensation for room EQ, offering control over sound presence for use in different spaces.
