The M-Audio Pulsar is a small-capsule condenser microphone with a cardioid polar pattern, a 3/4-inch, 6-micron evaporated-gold diaphragm, a solid brass body and capsule, a 20Hz-20kHz frequency response, Class A FET electronics, a 3-pin XLR (phantom-powered), and includes a soft case, pop filter, and hard mount
The M-Audio Pulsar is a top-address cardioid instrument microphone featuring a 6-micron evaporated-gold diaphragm and a solid brass body. It utilizes Class A FET electronics to produce a smooth tone suitable for recording acoustic instruments, wind instruments, overhead drums, or room ambience.
| Type | small diaphragm condenser |
|---|---|
| Polar Pattern | cardioid |
| Frequency Response | 20Hz – 20kHz |
| Sensitivity | 13.8 mV/Pa (-37dBV re 1V/Pa) |
| Max SPL for 0.5% THD | 134dB |
| Equivalent Noise Level | 17dB A-weighted |
| Output Impedance | 200 Ω |
| Connector | 3-pin male XLR |
| Dimensions | 22mm (0.87") dia, 132 mm (5.20") long |
| Weight | 115 g (4.0 oz) |
Always turn volume/gain down, ensure phantom power is off, connect via XLR cable, then slowly turn on phantom power. When disconnecting, reverse these steps.
Avoid temperature extremes above 95°F and below 50°F. Allow the microphone to acclimate to room temperature before connecting if moving between outdoor and indoor environments.
