The DAC08 is a high-speed, 8-bit, multiplying D/A converter with low cost and outstanding application flexibility. It features a 20:1 reference current range, 85 ns settling time, low power consumption, and TTL, CMOS, ECL, HTL, and PMOS logic interfaces.
This document provides technical specifications and application information for the DAC08 series of 8-bit monolithic digital-to-analog converters. The devices offer very high-speed performance with 85 ns settling times, low power consumption, and monotonic multiplying performance over a wide reference current range. They feature a direct interface to TTL, CMOS, ECL, HTL, and PMOS logic families.
| Resolution | 8 Bits |
|---|---|
| Settling Time | 85 ns |
| Nonlinearity | ±0.1% to ±0.39% |
| Power Dissipation | 33 mW to 174 mW |
| Operating Temperature | -55 °C to +125 °C |
| Logic Input Swing | -10 V to +18 V |
The DAC08 series achieves 85 ns settling times with very low glitch energy.
It provides a direct interface to TTL, CMOS, ECL, HTL, and PMOS logic families.
The maximum nonlinearity is 0.39% over the full scale.
