This document is the Owner's Manual for the Yamaha VIB41 Professional Series Mixer. It provides comprehensive instructions for operating the device, including details on input/output channels, mixing matrix, and monitor sections. The manual also covers installation features, optional functions, and applications such as sound reinforcement and recording systems.
| Total Harmonic Distortion | Less than 0.6% at +10 dB*output |
|---|---|
| Channel Equalization | High 10 kHz Shelving, MID 500, 700, 1 k, 1.6 k, 2.5 k, 3.5 kHz Peaking |
| Channel Inputs | 32 x CHANNEL IN (16 M1, 16 M2, both mic/line) |
| Mixer Outputs | 2x Main PGM (L&R): 4 x MTRX: 2 x FB: 2 x ECHO: 1 x CUE (preview) |
| Dimensions | 32-9/32" wide x 29-3/4" deep x 11-17/64" high |
| Weight | 94.8 pounds (43 kg) |
| Power Supply | U.S.A. : 120V 85W |
The mixer has 32 input channels, divided into 16 M1 and 16 M2.
The dimensions are 32-9/32 inches wide, 29-3/4 inches deep, and 11-17/64 inches high.
