The THS4061 and THS4062 are 180-MHz high-speed amplifiers, ideal for a wide range of applications including video, communication, and imaging. They offer 180-MHz bandwidth, 400 V/µs slew rate, and 40-ns settling time (0.1%). They have high output drive capability and low distortion.
The THS4061 and THS4062 are general-purpose, single and dual channel, high-speed voltage feedback amplifiers designed for applications including video, communication, and imaging. These devices offer excellent AC performance with a bandwidth of 180 MHz, a slew rate of 400 V/s, and a settling time of 40 ns to 0.1%. They are stable at all gains for both inverting and noninverting configurations.
| Bandwidth (-3 dB) | 180 MHz |
|---|---|
| Slew Rate | 400 V/s |
| Settling Time (0.1%) | 40 ns |
| Total Harmonic Distortion | -72 dBc |
| Output Current | 115 mA |
| Supply Current (per channel) | 7.8 mA |
| Differential Gain Error | 0.02% |
| Differential Phase Error | 0.02° |
The devices offer a bandwidth of 180 MHz at a gain of 1.
The devices are available in Standard SOIC, MSOP, PowerPAD, JG, or FK packages.
Yes, an evaluation module is available for these devices.
The maximum junction temperature is 150°C.
