The NMD series of DC-DC converters are ideally suited to applications where a potential difference exists between loads, eg motor control circuits. The twin outputs offer cost and space savings by consolidating two DC-DC Converters into one package. All of the rated power may be drawn from a single output provided the total load does not exceed 1 Watt.
The NMD series of DC-DC converters from C&D Technologies are isolated twin output devices ideally suited for applications where a potential difference exists between loads, such as motor control circuits. These converters consolidate two DC-DC converters into one package, offering cost and space savings. The series features twin independent outputs with 1kVDC isolation between outputs and input/output isolation, available in both SIP and DIP package styles.
| Rated Power | 1 W |
|---|---|
| Output Isolation | 1kVDC |
| Input/Output Isolation | 1kVDC |
| Efficiency | up to 80% |
| Power Density | 0.85W/cm² |
| Input Voltage | 5V & 12V |
| MTTF | up to 1.9 Million hours |
| Switching Frequency | 70 kHz |
| Operating Temperature | -55 to 125 °C |
| Storage Temperature | -55 to 150 °C |
The output isolation is 1kVDC.
No, no heatsink is required for these converters.
The NMD series supports 5V and 12V input voltages.
