The TL�F�6557 54174�DM54174�DM74174� 54175�DM54175�DM74175 Hex�Quad D Flip-Flops with Clear is a positive-edge triggered flip-flops that utilize TTL circuitry to implement D-type flip-flop logic.
This document provides technical specifications and application information for the National Semiconductor 54174 (Hex) and 54175 (Quad) D Flip-Flops with Clear. These positive-edge triggered devices utilize TTL circuitry to implement D-type flip-flop logic, suitable for use in buffer/storage registers, shift registers, and pattern generators.
| Typical Power Dissipation per Flip-Flop (174) | 38 mW |
|---|
Applications include buffer/storage registers, shift registers, and pattern generators.
Yes, the quad (175) version features complementary outputs from each flip-flop.
