The XC62G series is a highly precise, low power consumption positive voltage regulator manufactured using CMOS and laser trimming technologies. It achieves high output currents with low input-output voltage differentials. The series includes a high precision voltage reference, an error correction circuit, and an output driver with current limitation. It exhibits good transient responses and stable output even during load changes. It also has high ripple rejection ratios and can be used with low power supply noise. The CE input allows the output to be turned off, reducing power consumption. It is available in SOT-25 (150mW) and SOT-89-5 (500mW) packages.
The XC62G series are high-precision, low-power positive voltage regulators manufactured using CMOS and laser trimming technologies. They feature high output currents with low input-output voltage differentials and include a high-precision voltage reference, error correction circuit, and an output driver with current limitation.
Available in SOT-25 (150mW) and SOT-89-5 (500mW) packages, the series offers excellent transient response and high ripple rejection ratios. A key feature is the CE input pin, which allows the output to be turned off to reduce power consumption. The series also includes negative logic variants (XC62GP) for custom applications.
| Maximum Output Current | 150mA (V OUT=3.0V) |
|---|---|
| Output Voltage Range | 2.1V to 5.0V |
| Set-up Voltage Accuracy | ±2% |
| Supply Current (Typical) | 13 µA |
| Stand-by Supply Current | 0.1 µA |
| Output Voltage Temperature Characteristics | ±100ppm/°C |
| Input Stability | 0.2%/V |
The XC62G series is available in SOT-25 (150mW) and SOT-89-5 (500mW) packages.
The CE input enables the output to be turned off, which results in reduced power consumption.
Yes, an XC62GP series with negative logic is available as a custom option.
