About this manual

This document is a datasheet for the Powerex R500 and R501 series of general purpose rectifiers. The devices are rated for 100-150 Amperes average current and 1600 Volts, featuring standard and reverse polarities with color-coded ceramic seals. They are available with flag leads and stud terminals for various circuit configurations.

What's inside

Ordering Information
High Surge Current Ratings
Applications
Absolute Maximum Ratings
Electrical and Thermal Characteristics
Forward Voltage Drop
Reverse Leakage Current
Switching Characteristics
Thermal Resistance
Mounting Torque

Specifications

Average Forward Current	100-150 Amperes
Peak Reverse Voltage	1600 Volts
RMS Forward Current	160 Amperes (R500), 236 Amperes (R501)
Mounting Torque	120 (Lubricated)

Frequently asked questions

Are the R500 and R501 available in different polarities?

Yes, they are available with standard and reverse polarities with color-coded ceramic seals.

What is the average forward current rating for these rectifiers?

The R500 and R501 models are rated for an average forward current of 100 to 150 Amperes.

How much torque should be used when mounting the device?

You must apply a lubricated mounting torque of exactly 120 units as specified in the table.
