Analog Devices ADA4938-1 Ultra-Low Distortion Differential ADC Driver Datasheet

This document is about the datasheet of ADA4938-1, which is a low distortion differential ADC driver with extremely low harmonic distortion, low input voltage noise, high speed, fast settling and fast overdrive recovery

Brand: Analog Devices
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 9
File format: PDF
File size: 181 KB
Published: 08 June, 2012
Updated: 30 September, 2023
Model: ADA4938-1
MD5 checksum: 5E57EAC03F9F3031273A9BC06521B044
PDF: Analog Devices ADA4938-1 Ultra-Low Distortion Differential ADC Driver Datasheet PDF

About this manual

The ADA4938-1 is a low noise, ultra-low distortion, high speed differential amplifier fabricated using ADI's proprietary third generation high-voltage XFCB process. It is an ideal choice for driving high performance ADCs with resolutions up to 16 bits from dc to 70 MHz.

What's inside

Features
Applications
General Description
Specifications (Dual Supply)
Specifications (Single Supply)
Absolute Maximum Ratings
Thermal Resistance
Pin Configuration

Specifications

Slew Rate	4700 V/us
Third Harmonic Distortion (HD3)	-125 dBc @ 10 MHz
Input Voltage Noise (RTI)	2.2 nV/VHz
Operating Temperature Range	-40°C to +85°C

Frequently asked questions

What is the maximum operating temperature range?

The device operates over an extended industrial temperature range of -40°C to +85°C.

What is the ADA4938-1?

The ADA4938-1 is a low noise, ultra-low distortion, high speed differential amplifier.

What is the maximum output current?

The maximum output current is 95 mA.
