The content of the document is the supplier inquiry information of ADA10001S3C. The product has features and characteristics, but the specific features and characteristics need further analysis.
The ADA10001 is a monolithic IC intended for use in applications requiring high linearity, such as Cellular Telephone Base Station Driver Amplifiers and CATV Fiber Receiver/Distribution Amplifiers. It is supplied in a surface mount, 16 lead-SOIC package.
Key features include High Linearity (IIP3 +18 dBm), Low Noise Figure (2.0 dB), Single Supply operation (+8Vdc), and Wide Bandwidth from 50MHz to 1 GHz.
| Linearity (IIP3) | +18 dBm |
|---|---|
| Noise Figure | 2.0 dB |
| Supply Voltage | +8Vdc |
| Bandwidth | 50MHz - 1 GHz |
| Package Type | 16 Pin SOIC |
| Gain | 14 to 15 dB |
The device operates with a single positive supply of +8Vdc.
It supports a wide bandwidth from 50MHz to 1 GHz.
The amplifier provides a typical gain of 15 dB.
