Matsushita Electric Works PA 214 Slim Power Relay Datasheet

PA 214 is a compact relay produced by PA-RELAYS with wide control capacity, high sensitivity, high surge voltage and high breakdown voltage.

Brand: NAIS
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 3
File format: PDF
File size: 135 KB
Published: 08 June, 2012
Updated: 30 September, 2023
MD5 checksum: 9155220ACE13046E7284463E5DF2613E
PDF: Matsushita Electric Works PA 214 Slim Power Relay Datasheet PDF

About this manual

This document is a technical datasheet for the PA-RELAYS PA 214 series of slim power relays. The product line includes various models such as the PA1a (5V to 24V DC coils) designed for high-density mounting applications due to their compact dimensions of 5mm width and 12.5mm height.

What's inside

Features
Specifications
Typical Applications
Ordering Information
Types and Coil Data
Dimensions
Reference Data
Ambient Temperature Characteristics
Cautions for Use

Specifications

Width	5 mm
Height	12.5 mm
Nominal operating power (5-18V)	120 mW
Surge voltage between contacts and coil	4,000 V
Shock resistance (functional)	Min. 147 m/s² {15 G}
Compliance standard	IEC 1131-2 (TÜV)

Frequently asked questions

What is the typical application for this relay?

It serves as interface relays for programmable controllers and output relays for measuring equipment.

What is the standard packing quantity?

The standard packing consists of a tube containing 25 pieces or a case containing 1,000 pieces.

What is the ambient temperature range for operation?

The unit can operate in an ambient temperature range of –40 ° C to +70 ° C.

Is the relay UL/CSA approved?

Yes, the UL/CSA and TÜV approved type is standard for this product line.
