The LC66P2316 is an on-chip OTP PROM version of the LC6623XX Series CMOS 4-bit single-chip microcontrollers. It has a capacity of 16 kilobytes of OTP ROM and 512 × 4 bits of on-chip RAM. It fully supports the common instruction set of the LC66000 Series. It has 36 I/O ports, powerful timer functions and prescalers, and flexible I/O functions.
The Sanyo LC66P2316 is an on-chip OTP PROM version of the LC6623XX Series CMOS 4-bit single-chip microcontrollers. It is designed for program development, product evaluation, and prototype development, providing identical functionality and pin compatibility with the LC662316A mask ROM version. The device features a 16 KB on-chip OTP ROM capacity and 512 x 4 bits of on-chip RAM.
| ROM capacity | 16 kilobytes |
|---|---|
| Instruction set | 128 instructions |
| I/O ports | 36 pins |
| Operating supply voltage | 4.0 to 5.5 V |
| Packages | DIP42S, QFP48E |
It is appropriate for program development and product evaluation.
The LC66P2316 is an on-chip OTP PROM version of the Sanyo Four-Bit Single-Chip Microcontroller.
The instruction cycle time ranges from 0.95 to 10 microseconds at voltages between 4.0 and 5.5 V.
