The CAT140xx is an integrated circuit that includes a CMOS serial EEPROM memory and a system power monitor with brown-out protection. It supports 5V, 3.3V, 3V and 2.5V systems.
The CAT140xx family combines a precision power supply voltage monitor with a system power threshold voltage supervisor and brown-out protection. These devices are designed as memory and supervisory solutions for 5V, 3.3V, 3V, and 2.5V systems.
| Endurance | 1,000,000 Program/Erase Cycles |
|---|---|
| Data Retention | 100 Years |
| Operating Temperature Range | -40°C to +85°C |
| Supply Voltage Range | +2.5V to +5.5V |
| Memory Interface Protocol | Standard and Fast I²C |
The device supports 5V, 3.3V, 3V, and 2.5V systems.
The reset signal remains asserted for at least 140ms after the power supply voltage rises above the threshold.
The device can be stored between -65°C and +150°C.
