AD45048 is a dual operational amplifier with Rail-to-Rail output from ADI company, with wide voltage range (3.3V~24V), output current up to 230mA, bandwidth up to 65MHz, can be used in ADSL CPE applications, audio applications etc.
The AD45048 is a dual operational amplifier featuring a rail-to-rail output stage capable of swinging to within 0.5 V of the supply rails. It delivers high output current up to 230 mA peak into a 25 Ω load and supports a wide supply range from 3.3 V to 24V.
| Supply Voltage Range | 3.3 V to 24V |
|---|---|
| Output Current (Peak) | 230 mA |
| Voltage Noise Density | 4.5 nV/√Hz |
| -3 dB Bandwidth | 65 MHz |
The device can operate from -40°C to +85°C.
Yes, it is a drop-in replacement for TS613ID and EL1519CS.
