This document is a product manual for a limit temperature sensor. It contains information such as product features, specifications, and model numbers.
This document describes the EPCOS B59901 series of limit temperature sensors and probe assemblies. These devices feature an epoxy resin coating with tinned leads and a metal tag for easy mounting and good thermal coupling. They are designed to operate within specific threshold temperatures ranging from 60°C to 140°C.
| Max. operating voltage (Ta = 0... 40 °C) | 30 VDC |
|---|---|
| Max. measuring voltage (Ta - 25K... Tutt +23 K) | 7,5 VDC |
| Rated resistance (Vetce £2,5 V) | < 100 Q |
| Operating temperature range (V = Vinax) | -40/+ 40 °C |
The maximum operating voltage at temperatures between 0 and 40 °C is 30 VDC.
The sensors have characteristics for nominal threshold temperatures ranging from 90 to 160 °C.
The thermal threshold time is less than 20 seconds.
