This document describes the ASFL2 standard specifications and options, including applications, product features, and parameters.
This document provides technical data for the ABRACON ASFL2 Crystal Clock Oscillator, a compact surface-mount device (SMD) measuring 5.0 x 3.2 x 1.6 mm. It is designed as a 2.0V HCMOS / TTL compatible component suitable for applications such as CCD clocks in VTR cameras and equipment connected to PCs.
| Frequency Range | 1.544 MHz to 110 MHz |
|---|---|
| Operating Temperature | -10°C to +70°C |
| Supply Voltage | 2.5 Vdc + 10% |
| Dimensions | 5.0 x 3.2 x 1.6 mm |
The maximum supply current is 15 mA.
The device measures 5.0 x 3.2 x 1.6 mm.
The standard operating temperature ranges from -10°C to +70°C.
