ST 74LCX05 handbook

This document describes the features and characteristics of the 74LCX05 low voltage CMOS open drain hex inverter. The product features 5V tolerant inputs, high speed operation, power down protection, symmetrical output impedance, guaranteed PCI bus levels, wide operating voltage range, compatibility with 74 series 05, latch-up performance exceeding 500mA, and strong protection against static discharge and transient excess voltage.

Brand
STMicroelectronics
File format
PDF
Published
06 June, 2012
Updated
28 September, 2023
MD5 checksum
0C1B3C5AFB343553893C0E5D94EFD20E
PDF
ST 74LCX05 handbook PDF
Download PDF
