The MAX7408/MAX7411/MAX7412/MAX7415 5th-order, lowpass, elliptic, switched-capacitor filters (SCFs) operate from a single +5V (MAX7408/MAX7411) or +3V (MAX7412/MAX7415) supply. The devices draw only 1.2mA of supply current and allow corner frequencies from 1Hz to 15kHz, making them ideal for low-power post-DAC filtering and anti-aliasing applications.
The document details four models of 5th-order, lowpass, elliptic, switched-capacitor filters (SCFs) designed to operate from a single +5V supply (MAX7408/MAX7411) or +3V supply (MAX7412/MAX7415). These devices are intended for low-power post-DAC filtering and anti-aliasing applications, drawing only 1.2mA of supply current in operating mode and allowing corner frequencies from 1Hz to 15kHz.
The datasheet provides absolute maximum ratings, electrical characteristics including filter response, power requirements, and shutdown specifications. It also includes typical operating circuits, pin configurations, and graphs illustrating frequency response, phase response, supply current versus temperature, and total harmonic distortion plus noise.
| Corner-Frequency Range | 0.001 to 15 kHz |
|---|---|
| Supply Voltage | +5V or +3V |
| Supply Current (Operating) | 1.2mA |
| Total Harmonic Distortion plus Noise | -80dB |
| Output Offset Voltage | +/- 25 mV |
The devices offer self-clocking through an external capacitor or external clocking for tighter cutoff-frequency control.
The MAX7411 and MAX7415 have a transition ratio of 1.25.
